Complete Technical Specifications
Processor / System Bus
2 x Socket6th Intel® Xeon® Processor Scalable Family (Up to 350W)
Memory
Total Slots:32 (8 channel per CPU, 16 DIMM per CPU)Capacity:Maximum up to 4TB per CPU socketMemory Type:DDR5 6400 RDIMM/ 3DS RDIMM (2DPC)Memory Size:128GB, 96GB, 64GB* Refer to support page for more information
Expansion Slots
SKU1: 4 x PCIe Gen5 slots[PCIe Switch directly]-4 x PCIe Gen5 x16 linkSKU2: 5 x PCIe Gen5 slots[PCIe Switch directly]-4 x PCIe Gen5 x16 link-1 x PCIe Gen5 x8 link (Raid Only)*Support PCIe x16 link support DPU** For Raid card to connect storage
Storage
Optional Kits:-Broadcom MegaRAID 9540-8i
Networking
2 x 10 Gigabit LAN ports (Intel X710-AT2 Controller)1 x Management Port
Multi-GPU Support
NVIDIA HGX B300 288GB 8-GPU Baseboard
Front I/O Ports
2 x USB 3.2 ports1 x VGA port2 x 10GbE RJ45 LAN port1 x RJ-45 Mgmt LAN port
Switch/LED
Front :1 x Power Switch/LED1 x Location Switch/LED1 x Message LED1 x Port80 LED (Q-Code)LAN 1-2 LED (on NIC module)
OS Support
Please find the latest OS support from https://servers.asus.com/support/os
Management Solution
ASUS Control CenterOn-Board ASMB12-iKVM
Regulatory Compliance
CB, CE, FCC, BSMI
Dimensions
945mm * 447mm * 394.5 mm
Form Factor
9U
Weight
Net Weight kg (CPU, DRAM & HDD not included): 120kgGross Weight kg(CPU, DRAM & HDD not included,Packing include): 150kg
Power Supply
5+5 3200W 80 PLUS Titanium Power Supply
Environment
Operationtemperature: 10℃ ~ 35℃Nonoperation temperature: -40℃ ~ 70℃Nonoperation humidity: 20% ~ 90% ( Non condensing)
