Complete Technical Specifications
Feature 1
8-core CPU, 8GB RAM, 128GB of storage
Feature 2
48 TOPS for AI inferencing
Feature 3
48MP RGB camera
Active stereo
IR dot projector for improved stereo accuracy
Night vision
IR illumination LED for low-light or no-light environments
Feature 6
Microphone
Feature 7
Both USB3 and PoE for power and communication
Feature 8
Status LED
Feature 9
IP67 Rating
Feature 10
Running Linux based Luxonis OS
Feature 11
9-axis IMU
Base line
75 mm
Ideal depth range
70 cm - 12 m.
Power consumption
up to 25W
Housing
- Industrial grade aluminum with Front Gorilla Glass- Water resistance enclosure with IP67 rating
Mounts
- 1/4" tripod mount- 75mm M4 Vesa mount on back and bottom cover
Dimensions
143.5 x 42.5 x 67.3 mm
Weight
- 674g
Sensor
IMX586 (PY237)
DFOV
82.4˚
Resolution
48MP (8000x6000)
Focus
AF
Max Framerate
30 FPS
Spectral range
Visible
Shutter Type
Rolling
Sensor size
1/2"
F-number
1.79 ± 5%
Effective Focal Length
4.74mm
Pixel size
0.8µm
