reComputer Industrial J4011- Fanless Edge AI Device with Jetson Orin™ NX 8GB module
Seeed Studio
Overview
NVIDIA Jetson-based edge AI system for embedded AI and robotics. Includes 16GB unified memory for running local AI models. Ideal for autonomous systems, industrial automation, and smart edge deployments.
Key Features
- Dual ARM Cortex processors
- Up to 16GB DDR5 memory
- Integrated neural processing unit
- Optimized for edge deployment
Ideal For
AI Performance
reComputer Industrial J4012 - Orin NX 16GB, 100 TOPS reComputer Industrial J4011- Orin NX 8GB, 70 TOPS
GPU
1024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores
CPU
8-core Arm® Cortex®-A78AE v8.2 64-bit CPU (Orin NX 16GB) 6-core Arm® Cortex®-A78AE(Orin NX 8GB)
Memory
16GB 128-bit LPDDR5 (Orin NX 16GB) 8GB 128-bit LPDDR5 (Orin NX 8GB)
Video Decode
1x 8K30 (H.265) 2x 4K60 (H.265) 4x 4K30 (H.265) 9x 1080p60 (H.265) 18x 1080p30 (H.265)
Video Encode
1x 4K60 (H.265) 3x 4K30 (H.265) 6x 1080p60 (H.265) 12x 1080p30 (H.265)
DL Accelerator
2x NVDLA v2
Storage
1x M.2 Key M PCIe Gen4.0 SSD (M.2 NVMe 2280 SSD 128G included)
Networking
Ethernet
Wi-Fi
Support SMD Wi-Fi/Bluetooth (Module optional)
M.2 Key B
1x M.2 Key B support 4G/5G (Module optional)
I/O
USB
DI/DO
4x DI,4x DO, 3x GND_DI, 2x GND_DO, 1x GND_ISO,1x CAN
COM
1x DB9 (RS232/RS422/RS485)
Display
1x HDMI 2.0 Type A
SIM
1x Nano SIM card slot
Fan
Fanless, passive heatsink; 1x Fan connectors(5V PWM)
TPM
1x TPM 2.0 connector (Module optional)
RTC
1x RTC socket, 1x RTC 2-pin
Camera
2x CSI (2-lane 15pin)
Power
Power Supply
Power Adapter
19V Power Adapter(without power cord)
Mechanical
Dimensions (W x D x H)
Weight
1.57kg
Installation
Desk, DIN rail, wall-mounting, VESA
Environment
Operating Temperature
Operating Humidity
95% @ 40 °C (non-condensing)
Vibration
3 Grms @ 5 ~ 500 Hz, random, 1 hr/axis
Shock
50G peak acceleration (11 msec)
Warranty
2 Years
Fanless compact PC
Thermal reference design, wider temperature support -20 ~ 60°C with 0.7m/s airflow.
Industrial interfaces
2x RJ-45 GbE(1 for POE-PSE 802.3 af), 1x RS-232/RS-422/RS-485, 4x DI/DO, 1x CAN, 3x2, 1x TPM2.0 (Module optional).
Hybrid connectivity
Support 5G/4G/LTE/LoRaWAN®/GPS(Module optional) with 1x Nano SIM card slot.
Scale to deploy
support OTA, remote management services powered by Allxon.
Flexible mounting
Desk, DIN rail, wall-mounting, VESA.
Feature
AI Video Analytics
Feature
Machine Vision
Feature
Medical Imaging
Feature
Autonomous Mobile Robot (AMR)
Feature
Generative AI
Prices may vary. Verify on vendor site.
Quick Specs
- AI Performance
- reComputer Industrial J4012 - Orin NX 16GB, 100 TOPS reComputer Industrial J4011- Orin NX 8GB, 70 TOPS
- GPU
- 1024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores
- CPU
- 8-core Arm® Cortex®-A78AE v8.2 64-bit CPU (Orin NX 16GB) 6-core Arm® Cortex®-A78AE(Orin NX 8GB)
- Memory
- 16GB 128-bit LPDDR5 (Orin NX 16GB) 8GB 128-bit LPDDR5 (Orin NX 8GB)
- Video Decode
- 1x 8K30 (H.265) 2x 4K60 (H.265) 4x 4K30 (H.265) 9x 1080p60 (H.265) 18x 1080p30 (H.265)
- Video Encode
- 1x 4K60 (H.265) 3x 4K30 (H.265) 6x 1080p60 (H.265) 12x 1080p30 (H.265)
