Complete Technical Specifications
MBD-X13SEDW-F
Print
MBD-X13SEDW-F
Print
MBD-X13SEDW-F
Form Factor
Form Factor
Proprietary CloudDC
Dimension
13" x 13" (33.02cm x 33.02cm)
CPU
Single Socket E (LGA-4677) 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors *BIOS 2.1 or above is required to support 5th Gen Intel® Xeon® Scalable processors
Core Count
Up to 64C
Note
Supports up to 350W TDP CPUs
Memory
Slot Count: 16 DIMM Slots Max Memory (1DPC): Up to 2TB 5600MT/s ECC DDR5 RDIMM/3DS RDIMM Max Memory (2DPC): Up to 4TB 4400MT/s ECC DDR5 RDIMM/3DS RDIMM
DIMM Sizes
RDIMM:16GB, 24GB, 32GB, 48GB, 64GB, 96GB, 128GB 3DS RDIMM:128GB, 256GB
Memory Voltage
1.1V
Error Detection
Corrects single-bit errors Detects double-bit errors (using ECC memory)
Chipset
Intel® C741
SATA
12 SATA (6Gbps) via Intel® C741; RAID 0/1/5/10 support
IPMI
ASPEED AST2600 BMC
Network Controller
AIOM for LAN
LAN
1 RJ45 LAN port(s)
USB
2 USB 2.0 port(s) (header) 2 USB 3.2 Gen1 port(s) (Rear)
Video
1 Aspeed AST2600 BMC port(s) 1 VGA D-Sub Connector port(s)
Serial
1 COM port(s) (header)
TPM
1 TPM 2.0 Header
Form Factor
Proprietary CloudDC
Dimension
13" x 13" (33.02cm x 33.02cm)
CPU
Single Socket E (LGA-4677) 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors *BIOS 2.1 or above is required to support 5th Gen Intel® Xeon® Scalable processors
Core Count
Up to 64C
Note
Supports up to 350W TDP CPUs
Memory
Slot Count: 16 DIMM Slots Max Memory (1DPC): Up to 2TB 5600MT/s ECC DDR5 RDIMM/3DS RDIMM Max Memory (2DPC): Up to 4TB 4400MT/s ECC DDR5 RDIMM/3DS RDIMM
DIMM Sizes
RDIMM:16GB, 24GB, 32GB, 48GB, 64GB, 96GB, 128GB 3DS RDIMM:128GB, 256GB
Memory Voltage
1.1V
Error Detection
Corrects single-bit errors Detects double-bit errors (using ECC memory)
Chipset
Intel® C741
SATA
12 SATA (6Gbps) via Intel® C741; RAID 0/1/5/10 support
IPMI
ASPEED AST2600 BMC
Network Controller
AIOM for LAN
LAN
1 RJ45 LAN port(s)
USB
2 USB 2.0 port(s) (header) 2 USB 3.2 Gen1 port(s) (Rear)
Video
1 Aspeed AST2600 BMC port(s) 1 VGA D-Sub Connector port(s)
Serial
1 COM port(s) (header)
TPM
1 TPM 2.0 Header
PCI-Express (PCIe) Configuration
1 PCIe 5.0 x8 AIOM slot 1 PCIe 5.0 x0 AIOM slot 2 PCIe 5.0 x16 slots 8 PCIe 5.0 x4 via MCIO Connector slots 1 PCIe 5.0 x8 via MCIO Connector slot
BIOS Type
AMI UEFI
BIOS Features
ACPI 6.4 SMBIOS 3.5 UEFI 2.8 or above
Software
SuperCloud Composer® Supermicro Server Manager (SSM) Supermicro Power Manager (SPM) Supermicro Update Manager (SUM) Supermicro SuperDoctor® 5 (SD5) Super Diagnostics Offline (SDO) Supermicro Thin-Agent Service (TAS) SuperServer Automation Assistant (SAA) New! Plug-ins for 3rd Party Software IPMI Utilities
Hardware
Trusted Platform Module (TPM) 2.0
Voltage
+12V,+3.3V,+5V,+5V standby,Chassis intrusion header,Chipset voltage,Memory Voltages,Monitors CPU voltages,Supports system management utility,System level control
LED
CPU/system overheat LED UID/remote UID LED
Temperature
CPU thermal trip support Monitoring for CPU and chassis environment PECI Thermal monitor 2 (TM2) support
FAN
6x 4-pin fan headers (up to 6 fans) 6 fans with tachometer status monitoring Fan speed control Overheat LED indication
Other Features
ACPI power management Chassis intrusion detection Control of power-on for recovery from AC power loss M.2 NGFF connector Node manager support UID WOL
Environmental Spec.
Operating Temperature: -5°C to 55°C (23°F to 131°F ) Non-operating Temperature: -30°C to 60°C (-22°F to 140°F) Operating Relative Humidity: 8% to 80% Non-operating Relative Humidity: 8% to 90%
PCI-Express (PCIe) Configuration
1 PCIe 5.0 x8 AIOM slot 1 PCIe 5.0 x0 AIOM slot 2 PCIe 5.0 x16 slots 8 PCIe 5.0 x4 via MCIO Connector slots 1 PCIe 5.0 x8 via MCIO Connector slot
BIOS Type
AMI UEFI
BIOS Features
ACPI 6.4 SMBIOS 3.5 UEFI 2.8 or above
Software
SuperCloud Composer® Supermicro Server Manager (SSM) Supermicro Power Manager (SPM) Supermicro Update Manager (SUM) Supermicro SuperDoctor® 5 (SD5) Super Diagnostics Offline (SDO) Supermicro Thin-Agent Service (TAS) SuperServer Automation Assistant (SAA) New! Plug-ins for 3rd Party Software IPMI Utilities
Hardware
Trusted Platform Module (TPM) 2.0
Voltage
+12V,+3.3V,+5V,+5V standby,Chassis intrusion header,Chipset voltage,Memory Voltages,Monitors CPU voltages,Supports system management utility,System level control
LED
CPU/system overheat LED UID/remote UID LED
Temperature
CPU thermal trip support Monitoring for CPU and chassis environment PECI Thermal monitor 2 (TM2) support
FAN
6x 4-pin fan headers (up to 6 fans) 6 fans with tachometer status monitoring Fan speed control Overheat LED indication
Other Features
ACPI power management Chassis intrusion detection Control of power-on for recovery from AC power loss M.2 NGFF connector Node manager support UID WOL
Environmental Spec.
Operating Temperature: -5°C to 55°C (23°F to 131°F ) Non-operating Temperature: -30°C to 60°C (-22°F to 140°F) Operating Relative Humidity: 8% to 80% Non-operating Relative Humidity: 8% to 90%
