Complete Technical Specifications
MBD-X12DPG-OA6
Print
MBD-X12DPG-OA6
Print
MBD-X12DPG-OA6
Form Factor
Form Factor
Proprietary
Dimension
15" x 17" (38.1cm x 43.18cm)
CPU
3rd Gen Intel® Xeon® Scalable processorsDual Socket Socket P+ (LGA-4189) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s
Core
Up to 40 cores
Memory Capacity
32 DIMM slotsUp to 8GB Unbuffered Intel® Optane™ Persistent Memory 200 Series, DDR4-3200MT/sUp to 8TB 3DS ECC LRDIMM, DDR4-3200MT/s; Up to 8TB 3DS ECC RDIMM, DDR4-3200MT/s
Memory Type
ECC DDR4 LRDIMM (3DS), RDIMM (3DS)
DIMM Sizes
N/A
Memory Voltage
1.2V
Chipset
Intel® C621A
IPMI
ASPEED AST2600 BMC
Network Controllers
Dual LAN with 1GbE LAN via Intel® i350-AM2
SATA
8 SATA3 (6Gbps) port(s)
Video Output
1 VGA port(s)
Serial Port
1 COM
Form Factor
Proprietary
Dimension
15" x 17" (38.1cm x 43.18cm)
CPU
3rd Gen Intel® Xeon® Scalable processorsDual Socket Socket P+ (LGA-4189) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s
Core
Up to 40 cores
Memory Capacity
32 DIMM slotsUp to 8GB Unbuffered Intel® Optane™ Persistent Memory 200 Series, DDR4-3200MT/sUp to 8TB 3DS ECC LRDIMM, DDR4-3200MT/s; Up to 8TB 3DS ECC RDIMM, DDR4-3200MT/s
Memory Type
ECC DDR4 LRDIMM (3DS), RDIMM (3DS)
DIMM Sizes
N/A
Memory Voltage
1.2V
Chipset
Intel® C621A
IPMI
ASPEED AST2600 BMC
Network Controllers
Dual LAN with 1GbE LAN via Intel® i350-AM2
SATA
8 SATA3 (6Gbps) port(s)
Video Output
1 VGA port(s)
Serial Port
1 COM
PCIe
1 PCIe 4.0 x16 AIOM, 16 PCIe 4.0 x8
M.2
M.2 Interface: 2 PCIe 3.0 x4Form Factor: 2280/22110
BIOS Type
AMI UEFI
Software
SuperCloud Composer®, Supermicro Server Manager (SSM), Supermicro Power Manager (SPM), Supermicro Update Manager (SUM), Supermicro SuperDoctor® 5 (SD5), Super Diagnostics Offline (SDO), Supermicro Thin-Agent Service (TAS), SuperServer Automation Assistant (SAA) New!, Plug-ins for 3rd Party Software, IPMI Utilities
System Management Software
IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
Power Configurations
ACPI Power Management, Power supply monitoring
Hardware
Trusted Platform Module (TPM) 2.0
Voltage
VBAT, System temperature, PCH temperature, Memory temperature, Memory, CPU temperature, CPU, 1.2V (VDIMM), 1.05 (PCH), +5V standby, +5V, +3.3V, +12V, VRM temperature, Memory Voltages, CPU thermal trip support, 10 -fan status, +1.0V PCH
FAN
PWM fan speed controlFan speed controlDual Cooling Zone10x fans with tachometer monitoring
Other Features
Chassis intrusion detectionNCSI header
Operating Temperature Range
10°C - 35°C (50°F - 95°F)
Non-Operating Temperature Range
-40°C - 70°C (-40°F - 158°F)
Operating Relative Humidity Range
8% - 90% (non-condensing)
Non Operating Relative Humidity Range
5% - 95% (non-condensing)
PCIe
1 PCIe 4.0 x16 AIOM, 16 PCIe 4.0 x8
M.2
M.2 Interface: 2 PCIe 3.0 x4Form Factor: 2280/22110
BIOS Type
AMI UEFI
Software
SuperCloud Composer®, Supermicro Server Manager (SSM), Supermicro Power Manager (SPM), Supermicro Update Manager (SUM), Supermicro SuperDoctor® 5 (SD5), Super Diagnostics Offline (SDO), Supermicro Thin-Agent Service (TAS), SuperServer Automation Assistant (SAA) New!, Plug-ins for 3rd Party Software, IPMI Utilities
System Management Software
IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
Power Configurations
ACPI Power Management, Power supply monitoring
Hardware
Trusted Platform Module (TPM) 2.0
Voltage
VBAT, System temperature, PCH temperature, Memory temperature, Memory, CPU temperature, CPU, 1.2V (VDIMM), 1.05 (PCH), +5V standby, +5V, +3.3V, +12V, VRM temperature, Memory Voltages, CPU thermal trip support, 10 -fan status, +1.0V PCH
FAN
PWM fan speed controlFan speed controlDual Cooling Zone10x fans with tachometer monitoring
Other Features
Chassis intrusion detectionNCSI header
Operating Temperature Range
10°C - 35°C (50°F - 95°F)
Non-Operating Temperature Range
-40°C - 70°C (-40°F - 158°F)
Operating Relative Humidity Range
8% - 90% (non-condensing)
Non Operating Relative Humidity Range
5% - 95% (non-condensing)
