Complete Technical Specifications
Dimension (WxHxL)
ChassisForm Factor1UModelCSE-515B-R601W Dimensions and WeightHeight1.7" (43 mm)Width17.2" (437 mm)Depth16.9" (429 mm)Package8" (H) x 27" (W) x 24" (D)WeightGross Weight: 14.99 lbs (6.8 kg)Net Weight: 10.01 lbs (4.54 kg)Available ColorNo Paint Front PanelLEDFan Fail/System Over Heat LEDPower LEDButtonsPower On/Off button Expansion Slots PCI-Express (PCIe) ConfigurationDefault1 PCIe 4.0 x16 LP slot 2 PCIe 4.0 x16 FHFL slots View AOC Options Drive Bays / Storage Drive Bays ConfigurationDefault: Total 2 bays2 internal fixed 2.5" SATA drive bays View Drive OptionsM.21 M.2 NVMe/SATA slot (M-key 2280/22110)View M.2 Options System CoolingFansUp to 6 heavy duty fans with optimal fan speed controlAir Shroud1 Air Shroud Power Supply 2x 600W 2x 600W Redundant (1 + 1) Typical 90%+ Level (96%) power supplies Dimension (WxHxL)54.5 x 40 x 220 mm Input600W: -44--65Vdc / 50-60Hz +12VMax: 50A / Min: 0A Max: 50A 5V SBMax: 3A / Min: 0A Output TypeBackplanes (gold finger) Operating EnvironmentEnvironmental Spec.Operating Temperature: 0°C to 40°C (32°F to 104°F)Non-operating Temperature: -40°C to 70°C (-40°F to 158°F)Operating Relative Humidity: 8% to 90% (non-condensing)Non-operating Relative Humidity: 5% to 95% (non-condensing)
Dimension (WxHxL)
2x 600W 2x 600W Redundant (1 + 1) Typical 90%+ Level (96%) power supplies Dimension (WxHxL)54.5 x 40 x 220 mm Input600W: -44--65Vdc / 50-60Hz +12VMax: 50A / Min: 0A Max: 50A 5V SBMax: 3A / Min: 0A Output TypeBackplanes (gold finger)
Dimension (WxHxL)
2x 600W 2x 600W Redundant (1 + 1) Typical 90%+ Level (96%) power supplies Dimension (WxHxL)54.5 x 40 x 220 mm Input600W: -44--65Vdc / 50-60Hz +12VMax: 50A / Min: 0A Max: 50A 5V SBMax: 3A / Min: 0A Output TypeBackplanes (gold finger)
Dimension (WxHxL)
54.5 x 40 x 220 mm
Input
600W: -44--65Vdc / 50-60Hz
+12V
Max: 50A / Min: 0A Max: 50A
5V SB
Max: 3A / Min: 0A
Output Type
Backplanes (gold finger)
