Complete Technical Specifications
Dimension (WxHxL)
ChassisForm Factor2U RackmountModelCSE-211M Dimensions and WeightHeight3.5" (88.9 mm)Width17.2" (436.88 mm)Depth11.8" (298.8 mm)Package7.4" (H) x 19.3" (W) x 23.3" (D)WeightGross Weight: 22 lbs (10 kg)Net Weight: 17 lbs (7.7 kg)Available ColorSilver/Black Front PanelLEDHDD activityLAN1 activityLAN2 activityPower statusSystem informationButtonsPower On/Off UID button Expansion Slots PCI-Express (PCIe) ConfigurationDefault1 PCIe 3.0 x16 HHHL slot 2 PCIe 3.0 x16 FHHL slots View AOC Options Drive Bays / Storage Drive Bays ConfigurationDefault: Total 2 bays2 front hot-swap 2.5" SATA drive bays View Drive OptionsM.21 M.2 NVMe/SATA slot (M-key 2280/22110)View M.2 Options System CoolingFansUp to 4x 4-PIN PWM 8cm Fan(s) Power Supply 1x 600W 1x 600W Redundant Typical 90%+ Level (96%) power supply Dimension (WxHxL)54.5 x 40 x 220 mm Input600W: -44--65Vdc / 50-60Hz +12VMax: 50A / Min: 0A Max: 50A 5V SBMax: 3A / Min: 0A Output TypeBackplanes (gold finger) Operating EnvironmentEnvironmental Spec.Operating Temperature: 0°C to 35°C (32°F to 95°F)Non-operating Temperature: -40°C to 70°C (-40°F to 158°F)Operating Relative Humidity: 8% to 90% (non-condensing)Non-operating Relative Humidity: 5% to 95% (non-condensing)
Dimension (WxHxL)
1x 600W 1x 600W Redundant Typical 90%+ Level (96%) power supply Dimension (WxHxL)54.5 x 40 x 220 mm Input600W: -44--65Vdc / 50-60Hz +12VMax: 50A / Min: 0A Max: 50A 5V SBMax: 3A / Min: 0A Output TypeBackplanes (gold finger)
Dimension (WxHxL)
1x 600W 1x 600W Redundant Typical 90%+ Level (96%) power supply Dimension (WxHxL)54.5 x 40 x 220 mm Input600W: -44--65Vdc / 50-60Hz +12VMax: 50A / Min: 0A Max: 50A 5V SBMax: 3A / Min: 0A Output TypeBackplanes (gold finger)
Dimension (WxHxL)
54.5 x 40 x 220 mm
Input
600W: -44--65Vdc / 50-60Hz
+12V
Max: 50A / Min: 0A Max: 50A
5V SB
Max: 3A / Min: 0A
Output Type
Backplanes (gold finger)
