Complete Technical Specifications
Dimension (WxHxL)
ChassisForm Factor1U RackmountModelCSE-813MF2TS-350RCBP Dimensions and WeightHeight1.7" (43 mm)Width17.2" (437 mm)Depth19.98" (507 mm)Package8.5" (H) x 24" (W) x 29.5" (D)WeightGross Weight: 30.4 lbs (13.8 kg)Net Weight: 17.6 lbs (8 kg)Available ColorBlack Front PanelLEDDevice ActivityLAN 1 ActivityLAN 2 ActivityPower statusSystem informationButtonsPower On/Off System Reset Expansion Slots PCI-Express (PCIe) ConfigurationDefault1 PCIe 4.0 x8 FHFL slot 1 PCIe 4.0 x8 LP slot Option A1 PCIe 4.0 x16 FHFL slot View AOC Options Drive Bays / Storage Drive Bays ConfigurationDefault: Total 4 bays4 front hot-swap 3.5" SATA drive bays View Drive OptionsM.21 M.2 NVMe slot (M-key 2280/22110)View M.2 OptionsPeripheral Bays2 2.5" bays (optional) System CoolingFansUp to 4 middle cooling PWM 40x40x28mm Fan(s)Up to 2 AOC cooling Fan(s) (optional)Air Shroud1 Air Shroud Power Supply 1x 350W 1x 350W Platinum Level (93%) power supply Dimension (WxHxL)100 x 40 x 180 mm Input350W: 100-240Vac 350W: 100-240Vac / 50-60Hz +12VMax: 29A / Min: 0.5A (100Vac-240Vac)Max: 29A / Min: 0.5A 5V SBMax: 3A / Min: 0A Output Type24pin ATX Certification Platinum Level [ Test Report ] Operating EnvironmentEnvironmental Spec.Operating Temperature: 10°C to 35°C (50°F to 95°F)Non-operating Temperature: -40°C to 70°C (-40°F to 158°F)Operating Relative Humidity: 8% to 90% (non-condensing)Non-operating Relative Humidity: 5% to 95% (non-condensing)
Dimension (WxHxL)
1x 350W 1x 350W Platinum Level (93%) power supply Dimension (WxHxL)100 x 40 x 180 mm Input350W: 100-240Vac 350W: 100-240Vac / 50-60Hz +12VMax: 29A / Min: 0.5A (100Vac-240Vac)Max: 29A / Min: 0.5A 5V SBMax: 3A / Min: 0A Output Type24pin ATX Certification Platinum Level [ Test Report ]
Dimension (WxHxL)
1x 350W 1x 350W Platinum Level (93%) power supply Dimension (WxHxL)100 x 40 x 180 mm Input350W: 100-240Vac 350W: 100-240Vac / 50-60Hz +12VMax: 29A / Min: 0.5A (100Vac-240Vac)Max: 29A / Min: 0.5A 5V SBMax: 3A / Min: 0A Output Type24pin ATX Certification Platinum Level [ Test Report ]
Dimension (WxHxL)
100 x 40 x 180 mm
Input
350W: 100-240Vac 350W: 100-240Vac / 50-60Hz
+12V
Max: 29A / Min: 0.5A (100Vac-240Vac)Max: 29A / Min: 0.5A
5V SB
Max: 3A / Min: 0A
Output Type
24pin ATX
Certification
Platinum Level [ Test Report ]
