Complete Technical Specifications
Dimension (WxHxL)
ChassisForm FactorMid-TowerModelCSE-735D4-1K26B Dimensions and WeightHeight16.7" (424 mm)Width7.6" (193 mm)Depth20.68" (525.3 mm)Package21.38" (H) x 11.97" (W) x 25.28" (D)WeightGross Weight: 30 lbs (13.61 kg)Net Weight: 27 lbs (12.25 kg)Available Colorblack Front PanelLEDHDD activity LEDButtonsPower On/Off button Expansion Slots PCI-Express (PCIe) ConfigurationDefault5 PCIe 4.0 x16 FHFL slots 1 PCIe 4.0 x8 FHHL slot View AOC Options Drive Bays / Storage Drive Bays ConfigurationDefault: Total 4 bays4 internal fixed 3.5" NVMe*/SATA drive bays (*NVMe support may require additional storage controller and/or cables)View NVMe OptionsView Drive OptionsM.22 M.2 NVMe slots (M-key)View M.2 OptionsPeripheral Bays2 5.25" peripheral bays (optional) System CoolingFansUp to 2x 12cm Fan(s) Power Supply 1x 1200W 1x 1200W Platinum Level (94%) power supply Dimension (WxHxL)150 x 86 x 185 mm Input1000W: 100-120Vac / 50-60Hz 100-240Vac 1200W: 120-240Vac / 50-60Hz +12VMax: 83A / Min: 1A (100Vac-120Vac)Max: 99A / Min: 1A (120Vac-240Vac) 5V SBMax: 3A / Min: 0A Output Type24pin ATX Certification Platinum Level Operating EnvironmentEnvironmental Spec.Operating Temperature: 10°C to 35°C (50°F to 95°F)Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)Operating Relative Humidity: 8% to 90% (non-condensing)Non-operating Relative Humidity: 5% to 95% (non-condensing)
Dimension (WxHxL)
1x 1200W 1x 1200W Platinum Level (94%) power supply Dimension (WxHxL)150 x 86 x 185 mm Input1000W: 100-120Vac / 50-60Hz 100-240Vac 1200W: 120-240Vac / 50-60Hz +12VMax: 83A / Min: 1A (100Vac-120Vac)Max: 99A / Min: 1A (120Vac-240Vac) 5V SBMax: 3A / Min: 0A Output Type24pin ATX Certification Platinum Level
Dimension (WxHxL)
1x 1200W 1x 1200W Platinum Level (94%) power supply Dimension (WxHxL)150 x 86 x 185 mm Input1000W: 100-120Vac / 50-60Hz 100-240Vac 1200W: 120-240Vac / 50-60Hz +12VMax: 83A / Min: 1A (100Vac-120Vac)Max: 99A / Min: 1A (120Vac-240Vac) 5V SBMax: 3A / Min: 0A Output Type24pin ATX Certification Platinum Level
Dimension (WxHxL)
150 x 86 x 185 mm
Input
1000W: 100-120Vac / 50-60Hz 100-240Vac 1200W: 120-240Vac / 50-60Hz
+12V
Max: 83A / Min: 1A (100Vac-120Vac)Max: 99A / Min: 1A (120Vac-240Vac)
5V SB
Max: 3A / Min: 0A
Output Type
24pin ATX
Certification
Platinum Level
