Complete Technical Specifications
Chipset
AMD X870E
Socket
Single (AM5)
CPU Cooling
Liquid-Cooled (closed loop)
Processor
AMD Ryzen 9000
Core Frequency (GHz)
4.3 Base / 5.7 Boost clock
Cores/Threads
16/32
Multi-Threading
Yes
Max Configurable Memory
192GB DDR5-5600MHz
DIMM Slots
4
PCIe Slots
x16, x16(x8)
Supported GPU Configurations
① x16 ② x16/x8
2.5" Drive(s)
4 (Up to 8TB each)
3.5" Drive(s)
2 (Up to 18TB each)
Shipping Dimensions
21" (53.34cm) W15" (38.10cm) H24" (60.96cm) D
Shipping Weight
35 Lbs.
Anti-Theft Feature
Kensington® Security Slot
M.2 Drive(s)
2 (Up to 4TB each)
U.2 Support
No
RAID Support
0, 1, 10
OCuLink Support
No
Max 2.5"/3.5" Configurations
2 x 3.5" | or |
1 x 3.5" +
2 x 2.5" | or |
4 x 2.5"
Onboard Wi-Fi
802.11ab (Wi-Fi 7)
Onboard Bluetooth
V5.2
Power Supply
750W
GPU Power Budget (W)
400
Product Dimensions
6.84" (17.37cm) W15.28" (38.81cm) H17.80" (45.21cm) D
Front I/O
2 x USB 3.2 Gen 2 Type A
1 x USB 3.2 Gen 2 Type CAudio Out/Mic In
Rear I/O
1 x 5 Gigabit LAN (RJ-45)
2 x USB 4.0 (USB Type-C)
3 x USB 3.2 Gen 1 (Type-A)
5 x USB 3.2 Gen 2 (Type-A)
7.1-Channel HD Audio
1 x Optical SPDIF Out
2 x Antenna
1 x HDMI
Optical Drive Option
No
Rackmount Option
No
Notes
Highest available CPU core count and associated clock speeds shown. Other processors with different core counts and frequencies may be available.GPU power budgets are conservative estimates.Shipping weights vary by configuration.
