Complete Technical Specifications
Processor & Chipset
Number of Processors Supported:
1
Processor Socket:
Socket SP5 LGA-6096
Processor Type:
- EPYC
Processor Supported:
- 9004-Series
- 9005-Series
Thermal Design Power (TDP):
Up to 240W
Chipset Manufacturer:
AMD
Chipset Model:
SoC
Memory
Maximum Memory:
3 TB
Memory Technology:
DDR5 SDRAM
Memory Standard:
DDR5-4800/PC5-38400
Number of Total Memory Slots:
12
Controllers
Controller Type:
SATA3
RAID Supported:
No
Display & Graphics
Graphics Controller Manufacturer:
ASPEED
Graphics Controller Model:
AST2600
Network & Communication
Ethernet Technology:
1000BASE-T
Number of Network (RJ45) Ports:
2
I/O Expansions
PCI Express:
- 8x PCI-E 5.0 x16 slots (4x Double-Wide or 8x Single-Wide card support)
- 1x PCI-E 5.0 x16 slots (Full-Height/Half-Length)
- 1x PCI-E 5.0 x16 slots (x16/x8 ,Full-Height/Half-Length, optional OCP)
- 1x PCI-E 5.0 x8 slots (Low-Profile)
Drive Bays
Hot-Swap:
- 2x 2.5" SATA/NVMe Hot-Swap Drive Bays
- 2x 3.5" SATA/NVMe Hot-Swap Drive Bays
- 2x 3.5" SATA Hot-Swap Drive Bays
Interfaces/Ports
Total Number of USB 3.2 Gen 1 Ports:
4 (2x front, 2x rear)
Number of SATA Interfaces:
6
Number of NVMe Interfaces:
4
LAN:
- 2x 1000BASE-T Ports
- 1x RJ45 Dedicated IPMI Port
Onboard Video:
- 1x VGA
Power Description
Number of Power Supplies:
2
Redundant Power Supplies:
Yes
Maximum Power Supply Wattage:
2600 W
Certification:
80 Plus Titanium
Physical Characteristics
Color:
Black
Form Factor:
Rack-mountable
Rack Height:
2U
Height:
3.5"
Width:
17.30"
Depth:
31.50"
