Complete Technical Specifications
Processor & Chipset
Number of Processors Supported:
2
Processor Socket:
Socket SP5 LGA-6096
Processor Type:
EPYC
Processor Supported:
- 9005-Series
- 9004-Series
Thermal Design Power (TDP):
500 W
Chipset Manufacturer:
N/A
Chipset Model:
SoC
Memory
Memory Technology:
- DDR5 SDRAM
Memory Standard:
DDR5-4800/PC5-38400
Number of Total Memory Slots:
24
Controllers
NVMe:
- Via SoC
Display & Graphics
Graphics Controller Manufacturer:
ASPEED
Graphics Controller Model:
AST2600
I/O Expansions
PCI Express:
- 10x PCI-E 5.0 x16 + 2x x8 slots (Rear, Supports 10x double-wide cards)
- 1x PCI-E 5.0 x16 slot (Rear, Supports single-wide card)
- 2x PCI-E 5.0 x8 slot (Front, FHHL)
- 1x PCI-E 5.0 x8 OCP3.0 slot (Front)
- 2x PCI-E 3.0 x4 M.2 slots (22110/2280)
Drive Bays
Hot-swap:
- 24x 2.5" Hot-swap drive bays
- Default 16x NVMe
- Optional 24x SATA/SAS
- Requires additional controller card to support SATA/SAS
Interfaces/Ports
Total Number of USB 3.2 Gen1 Ports:
6 (4x front, 2x rear)
Number of NVMe Interfaces:
- 16x NVMe U.2
- 2x NVMe M.2
LAN:
- 2x 1000BASE-T RJ45 LAN Port (Front/Rear shared, 1GbE)
- 1x RJ45 IPMI dedicated LAN Port (Front/Rear shared, 1GbE)
Onboard Video:
1x VGA Connector (Front/Rear)
Power Description
Number of Power Supplies:
4
Redundant Power Supplies:
Yes (3+1)
Maximum Power Supply Wattage:
3200 W
Certification:
80 Plus Platinum
Physical Characteristics
Color:
Black
Form Factor:
Rack-mountable
Rack Height:
4U
Height:
6.9"
Width:
17.2"
Depth:
30.9"
