Complete Technical Specifications
Processor & Chipset
Number of Processors Supported:
2
Processor Socket:
Socket E2 LGA-4710
Processor Type:
Xeon 6
Processor Supported:
- 6700E-Series
- 6700P-Series
- 6500P-Series
Thermal Design Power (TDP):
400 W
Chipset Manufacturer:
N/A
Chipset Model:
SoC
Memory
Memory Technology:
- DDR5 SDRAM
Memory Standard:
- DDR5-6400/PC5-51200 RDIMM (1DPC)
- DDR5-5200/PC5-41600 RDIMM (2DPC)
Number of Total Memory Slots:
32
Controllers
NVMe:
- Via SoC
Display & Graphics
Graphics Controller Manufacturer:
ASPEED
Graphics Controller Model:
AST2600
Network & Communication
Ethernet Technology:
- 1000BASE-T
I/O Expansions
PCI Express:
- 10 PCI-E 5.0 x16 FHFL slots (Rear, Supports Double-Wide cards)
- 1x PCI-E 5.0 x16 FHFL slots (Rear, Supports Single-Wide card)
- 2x PCI-E 5.0 x16 FHHL slots (Front)
- 1x PCI-E 5.0 x16 OCP3.0 slot (Front)
- 1x PCI-E 5.0 x4 M.2 slot (2280/22110)
Drive Bays
Hot-swap:
- 24x 2.5" hot-swap drive bays
- Supports 18x NVMe U.2
- Storage card required for SATA/SAS
Interfaces/Ports
USB Ports:
- 4x USB3.2 Gen1 ports (Front, Type A)
- 2x USB3.2 Gen1 ports (Rear, Type A)
Number of NVMe Interfaces:
- 18x U.2
- 1x M.2
LAN:
- 2x 1000BASE-T (1GbE) Ports
- 1x RJ45 Management Port
Onboard Video:
1x VGA
Trusted Platform Module:
1x TPM Header with SPI interface (Optional)
Power Description
Number of Power Supplies:
4
Redundant Power Supplies:
Yes (3+1)
Maximum Power Supply Wattage:
3200 W
Certification:
80 Plus Titanium
Physical Characteristics
Color:
Black
Form Factor:
Rack-mountable
Rack Height:
4U
Height:
6.9"
Width:
17.2"
Depth:
30.9"
