Complete Technical Specifications
Processor & Chipset
Number of Processors Supported:
2
Processor Socket:
Socket SP5 LGA-6096
Processor Type:
EPYC
Processor Supported:
- 9005-Series
- 9004-Series
Thermal Design Power (TDP):
500 W
GPU:
8x NVIDIA H200 SXM
Chipset Manufacturer:
N/A
Chipset Model:
SoC
Memory
Memory Technology:
- DDR5 SDRAM
Memory Standard:
DDR5-6000/PC4-48000
Number of Total Memory Slots:
24
Controllers
NVMe:
- Via SoC/PCIe Switch Board
Display & Graphics
Graphics Controller Manufacturer:
ASPEED
Graphics Controller Model:
AST2600
Network & Communication
Ethernet Technology:
- 2x 1000BASE-T (1GbE, front or rear)
I/O Expansions
PCI Express:
- 8x PCI-E 5.0 x16 HHHL slots
- 1x PCI-E 5.0 x16 FHHL slot
- 1x PCI-E 3.0 x2 or SATA M.2 slot (2280/22110)
- 1x PCI-E 3.0 x4 or SATA M.2 slot (2280/22110)
Drive Bays
Hot-swap:
- 12x 2.5 hot-swap drive bays
- Supports NVMe drives
Interfaces/Ports
Total Number of USB 3.2 Gen1 Ports:
6 (4x Front, 2x Rear)
Number of NVMe Interfaces:
- 12x U.2
- 2x M.2
LAN:
- 2x RJ45 1000BASE-T Ports (Shared with front and rear I/O)
- 1x RJ45 Dedicated IPMI Port (Shared with front and rear I/O)
Onboard Video:
1x VGA Connector (Shared with front and rear I/O)
Power Description
Number of Power Supplies:
8
Redundant Power Supplies:
Yes (4+4)
Maximum Power Supply Wattage:
3002.4 W
Certification:
80 Plus Titanium
Physical Characteristics
Color:
Black
Form Factor:
Rack-mountable
Rack Height:
6U
Height:
10.4"
Width:
17.6"
Depth:
36.6"
