Complete Technical Specifications
Processor & Chipset
Number of Processors Supported:
2
Processor Socket:
Socket E LGA-4677
Processor Type:
Xeon
Processor Supported:
- Bronze 34XX
- Bronze 35XX
- Silver 44XX
- Silver 45XX
- Gold 54XX
- Gold 55XX
- Gold 64XX
- Gold 65XX
- Platinum 84XX
- Platinum 85XX
Thermal Design Power (TDP):
350 W
GPU:
8x NVIDIA H100 SXM5
Chipset Manufacturer:
Intel
Chipset Model:
C741
Memory
Memory Technology:
- DDR5 SDRAM
Memory Standard:
DDR5-4800/PC4-38400
Number of Total Memory Slots:
32
Controllers
SATA3:
- Via C741 chipset
Display & Graphics
Graphics Controller Manufacturer:
ASPEED
Graphics Controller Model:
AST2600 BMC
Network & Communication
Ethernet Technology:
- Optional AOC
I/O Expansions
PCI Express:
- 8x PCI-E 5.0 x16 slots (Low-Profile)
- 2x PCI-E 5.0 x16 slots (Full-Height/Full-Length)
- Optional 2x PCI-E 5.0 x16 slots (Full-Height/Full-Length)
- 2x PCI-E 5.0 x4 M.2 slots (Boot only)
Drive Bays
Hot-swap:
- 19x 2.5 hot-swap drive bays
- Up to 16x NVMe
- Up to 3x SATA
Interfaces/Ports
Total Number of USB 3.0 Ports:
2 (Rear)
Number of SATA Interfaces:
3
Number of NVMe Interfaces:
9
LAN:
- 1x RJ45 Dedicated IPMI Port
Onboard Video:
1x VGA Connector
Power Description
Number of Power Supplies:
6
Redundant Power Supplies:
Yes
Maximum Power Supply Wattage:
3000 W
Certification:
80 Plus Titanium
Physical Characteristics
Color:
Black
Form Factor:
Rack-mountable
Rack Height:
8U
Height:
14"
Width:
17.2"
Depth:
33.2
