Complete Technical Specifications
Processor & Chipset
Number of Processors Supported:
1
Processor Socket:
Socket AM5 LGA-1718
Processor Type:
- Ryzen
Processor Supported:
- Ryzen 5 7000 Series
- Ryzen 7 7000 Series
- Ryzen 9 7000 Series
- Ryzen 5 9000 Series
- Ryzen 7 9000 Series
- Ryzen 9 9000 Series
Thermal Design Power (TDP):
170W
Chipset Manufacturer:
AMD
Chipset Model:
X870E
Memory
Maximum Memory:
192 GB
Memory Technology:
DDR5 SDRAM
Memory Standard:
DDR5-5200/PC5-41600
Number of Total Memory Slots:
4
Controllers
SATA3:
- Via X870E chipset
Display & Graphics
Graphics Controller Manufacturer:
AMD
Graphics Controller Model:
RDNA 2
Network & Communication
Ethernet Technology:
- 2.5GBASE-T
- 10GBASE-T
I/O Expansions
PCI Express:
- 2x PCI-E 5.0 x16 slot (x16 or x8/x8, Supports 2x Double-Wide cards)
- 1x PCI-E 4.0 x4 (In x16 slot)
- 1x PCI-E 5.0 x4 M.2 slot (Up to 2280)
- 1x PCI-E 5.0 x4 M.2 slot (Up to 2280, Shared with PCI-E 5.0 x16 slot)
- 1x PCI-E 4.0 x4 M.2 slot (Up to 2280)
- 1x PCI-E 4.0 x4 M.2 slot (Up to 22110)
Drive Bays
Internal:
- 2x 2.5" fixed drive bay
- 6x 2.5"/3.5" fixed drive bay
Interfaces/Ports
USB Ports:
- 2x USB 3.0 (front)
- 1x USB 3.2 Gen 2 (front, Type-C)
- 2x USB 40Gbps (rear, Type-C)
- 1x USB 420Gbps (rear, Type-C)
- 7x USB 10Gbps (rear, Type-A)
- 1x USB 2.0 (rear, Type-A)
Number of SATA Interfaces:
4
LAN:
- 1x RJ45 2.5GBASE-T Ethernet LAN Port
- 1x RJ45 10GBASE-T Ethernet LAN Port
Wireless:
- Wi-Fi 7 (802.11be)
- Bluetooth 5.4
Onboard Video:
- HDMI
- USB 4 (Requires DisplayPort adapter cable)
Onboard Audio:
- 7.1 High Definition Realtek Audio CODEC
Power Description
Number of Power Supplies:
1
Redundant Power Supplies:
No
Physical Characteristics
Color:
Black
Form Factor:
Mid-Tower
Height:
18.66"
Width:
9.45"
Depth:
21.34"
