Complete Technical Specifications
Processor & Chipset
Number of Processors Supported:
1
Processor Manufacturer:
AMD
Processor Socket:
Socket sTR5
Processor Type:
- Ryzen
Processor Supported:
- Threadripper Pro 9000 WX-Series
- Threadripper Pro 7000 WX-Series
Chipset Manufacturer:
AMD
Chipset Model:
WRX90
Memory
Memory Technology:
DDR5 SDRAM
Memory Standard:
DDR5-5200/PC5-41600
Number of Total Memory Slots:
8
Controllers
SATA3:
- Via WRX90 chipset
- RAID 0, 1, 5, 10
NVMe:
- Via CPU & WRX90 Chipset
- RAID 0, 1, 5, 10
Network & Communication
Ethernet Technology:
- 10GBASE-T (10GbE)
I/O Expansions
PCI Express:
- 6x PCI-E 5.0 x16 slots (Supports 4x double-wide cards)
- 1x PCI-E 5.0 x8 (in x16 slot)
- 2x PCI-E 5.0 x4 M.2 slots (Up to 22110)
- 2x PCI-E 5.0 x4 M.2 slots (Up to 2280)
Drive Bays
Fixed:
- 4x 3.5"/2.5" SATA Fixed
- Optional 2x 2.5" U.2 Fixed
Interfaces/Ports
Number of USB Ports:
- 1x USB 3.1 Gen 2 (front, Type C)
- 2x USB 3.0 (front)
- 2x USB 4.0 (rear, Type C)
- 6x USB 3.2 Gen 2 (rear, Type A)
- 1x USB 2.0 (rear, Type A)
Number of SATA Interfaces:
- 4
NVMe:
- 2x PCI-E 5.0 x4 M.2 slots (Up to 22110)
- 2x PCI-E 4.0 x4 M.2 slot (Up to 2280)
- Optional 2x U.2 via SlimSAS slots
LAN:
- 1x RJ45 10GBASE-T Ethernet LAN Ports 10GbE)
- 1x RJ45 Management LAN Port (1GbE)
Audio:
- HD Audio
Power Description
Number of Power Supplies:
1
Redundant Power Supplies:
No
Physical Characteristics
Color:
Black
Form Factor:
Full-Tower
Height:
22.83"
Width:
9.45"
Depth:
22.05"
