Complete Technical Specifications
Processor & Chipset
Number of Processors Supported:
1
Processor Socket:
Socket E LGA-4677
Processor Type:
Xeon
Processor Supported:
- W-2400
Thermal Design Power (TDP):
N/A
Chipset Manufacturer:
Intel
Chipset Model:
W790
Memory
Maximum Memory:
2 TB
Memory Technology:
- DDR5 SDRAM
Memory Standard:
DDR5-4800/PC4-38400
Number of Total Memory Slots:
8
Controllers
SATA3:
- Via optional Intel VROC HW key
- SATA RAID 0, 1, 5, 10
- PCI-E RAID 0, 1, 5, 10
Display & Graphics
Graphics Controller Manufacturer:
N/A
Graphics Controller Model:
N/A
Network & Communication
Ethernet Technology:
- 2.5GBASE-T
I/O Expansions
PCI Express:
- 5x PCI-E 5.0 x16 slots (Supports 2x Double-Wide cards, x16/x16/x16/x0/x16 or x16/x16/x16/x8/x8)
- 1x PCI-E 4.0 x4 M.2 slot (Up to 22110)
- 1x PCI-E 4.0 x4 M.2 slot (Up to 2280)
Drive Bays
Fixed:
- 6x 3.5"/2.5" internal
- 2x 2.5" internal
Interfaces/Ports
USB Ports:
- 1x USB 3.1 Gen 2 port (front, Type-C)
- 2x USB 3.0 ports (front, Type-A)
- 1x USB 3.2 Gen 2x2 port (rear, Type-C)
- 4x USB 3.2 Gen 2 ports (rear, Type-A)
- 8x USB 2.0 ports (rear, Type-A)
Number of SATA Interfaces:
- 4x SATA3 Ports
Number of NVMe Interfaces:
- 3x U.2
- 2x M.2
LAN:
- 1x RJ45 10GBASE-T Ethernet LAN Port
- 1x RJ45 2.5GBASE-T Ethernet LAN Port
Onboard Video:
N/A
Onboard Audio:
7.1 HD Audio w/ optical S/PDIF
Serial Port / Header:
1x COM Header
TPM:
1x SPI TPM Header
Power Description
Number of Power Supplies:
1
Redundant Power Supplies:
No
Physical Characteristics
Color:
Black
Form Factor:
Mid-Tower
Height:
18.66"
Width:
9.45"
Depth:
21.34"
