Overview
NVIDIA Jetson Nano Developer Kit is a developer kit from Seeed Studio built on the NVIDIA Jetson Nano module. Its GPU is 128-core Maxwell. It carries 4 GB 64-bit LPDDR4 25.6 GB/s. Seeed publishes a fixed price for this configuration.
Key Features
- Built on the Jetson Nano module
- GPU: 128-core Maxwell
- CPU: Quad-core ARM A57 @ 1.43 GHz
- Memory: 4 GB 64-bit LPDDR4 25.6 GB/s
- Storage: microSD (not included)
- Camera input: 1x MIPI CSI-2 DPHY lanes
Ideal For
developers prototyping on the Jetson Nano before committing to a production carrier
GPU
128-core Maxwell
CPU
Quad-core ARM A57 @ 1.43 GHz
Memory
4 GB 64-bit LPDDR4 25.6 GB/s
Storage
microSD (not included)
Video Encoder
4K @ 30 | 4x 1080p @ 30 | 9x 720p @ 30 (H.264/H.265)
Video Decoder
4K @ 60 | 2x 4K @ 30 | 8x 1080p @ 30 | 18x 720p @ 30|(H.264/H.265)
Camera
1x MIPI CSI-2 DPHY lanes
Connectivity
Gigabit Ethernet, M.2 Key E
Display
HDMI 2.0 and eDP 1.4
USB
4x USB 3.0, USB 2.0 Micro-B
Others
GPIO, I2C, I2S, SPI, UART
Mechanical
100 mm x 80 mm x 29 mm
Feature
128-core NVIDIA Maxwell™ GPU
Feature
Quad-core ARM® A57 CPU
Feature
4 GB 64-bit LPDDR4
Feature
10/100/1000BASE-T Ethernet
Feature
Micro-USB 5V 2A
Feature
DC power adapter 5V 4A
Feature
USB 3.0 Type A
Feature
USB 2.0 Micro-B
Feature
HDMI/DisplayPort
Feature
Gigabit Ethernet
Feature
GPIOs, I2 C, I2 S, SPI, UART
Feature
MIPI-CSI camera connector
Feature
Fan connector
Feature
PoE connector
Feature
NVIDIA Jetson Nano module and carrier board
Feature
Quick Start Guide and Support Guide
Feature
Jetson Nano Metal Armour - Case with PWM Adjustment Fan $9.90
Feature
Aluminum Case for Nvidia Jetson Nano $29.90
Prices may vary. Verify on vendor site.
Quick Specs
- GPU
- 128-core Maxwell
- CPU
- Quad-core ARM A57 @ 1.43 GHz
- Memory
- 4 GB 64-bit LPDDR4 25.6 GB/s
- Storage
- microSD (not included)
- Video Encoder
- 4K @ 30 | 4x 1080p @ 30 | 9x 720p @ 30 (H.264/H.265)
- Video Decoder
- 4K @ 60 | 2x 4K @ 30 | 8x 1080p @ 30 | 18x 720p @ 30|(H.264/H.265)
