Overview
The NVIDIA RTX 4000 SFF Ada Generation is a Small Form Factor professional GPU built on NVIDIA's 4nm Ada Lovelace process with 20GB GDDR6 ECC in a low-profile dual-slot PCIe 4.0 design. Its 70W TDP makes it ideal for compact workstations and space-constrained deployments, delivering 19.2 TFLOPS FP32 and 306.8 TFLOPS Tensor performance.
Key Features
- 20GB GDDR6 ECC on Ada Lovelace 4nm TSMC process
- Low-profile dual-slot SFF design for compact systems
- 70W TDP with active fansink cooling
- 306.8 TFLOPS 4th-gen Tensor Core performance
- PCIe 4.0 x16 with 320 GB/s memory bandwidth
Ideal For
Enterprise IT and developers deploying AI inference in compact workstations or space-constrained industrial PCs requiring professional reliability.
Architecture
NVIDIA Ada Lovelace Architecture
Process Size
4nm NVIDIA Custom Process | TSMC
Die Size
294.5 mm2
Transistors
35.8 Billion
CUDA Cores
6144
Tensor Cores
192 | Gen 4
RT Cores
48 | Gen 3
FP32 Performance1
19.2 TFLOPS
Tensor Performance1
306.8 TFLOPS2
RT Core Performance1
44.3 TFLOPS
GPU Memory
20 GB GDDR6 ECC
Memory Interface
160-bit
Memory Bandwidth
320 GB/s
Display Connectors
mDP 1.4a (4)3
Graphics Bus
PCIE Express 4.0 x16
Form Factor
2.7” H x 6.6”L | Low Profile Dual Slot
Thermal Solution
Active Fansink
AR/MR/VR/XR Capable
Yes
NVIDIA 3D Vision and 3D Vision Pro
Support via Optional 3-pin mini-DIN
Frame Lock
Compatible with NVIDIA Quadro Sync II
Maximum Power Consumption
70W | No Auxiliary Power Required
NVENC | NVDEC
2x | 2x | Includes AV1 encode and Decode
Prices may vary. Verify on vendor site.
