Complete Technical Specifications
Feature 1
150° DFOV for stereo pair, either 120° or 150° for central camera depending on variant chosen
Active stereo
IR dot projector improves depth perception, especially for low-visual-interest surfaces by projecting thousands of IR dots to the scene.
Night vision
IR illumination LED enables running your AI and CV algorithms in low-light or no-light environments
Feature 4
Rugged IP66 rated enclosure (please see technical specifications for details)
Feature 5
USB2 / USB3 for power delivery and communication
Variant
IMX378
Sensor
IMX378 (PY060)
DFOV / HFOV / VFOV
120° / 95° / 93°
Resolution
12MP (4056x3040)
Focus
FF: 60cm - ∞
Max Framerate
60 FPS
Spectral range
Visible + 940nm
Shutter Type
Rolling
Sensor size
1/2.3”
F-number
1.8 ± 5%
Effective Focal Length
2.75mm
Pixel size
1.55µm
