Complete Technical Specifications
Applications Processor(AP)
NVIDIA Orin™ Nano 4GB
AI Performance
Orin Nano 4GB – 34 TOPS(MAXN_SUPER)
GPU
512-core NVIDIA Ampere architecture GPU with 16 Tensor Cores
GPU Max Frequency
1020 MHz (MAXN_SUPER)
CPU
6-core Arm® Cortex®-A78AE
CPU Max Frequency
1.7 GHz (MAXN_SUPER)
Memory
4GB 64-bit wide LPDDR5 DRAM(up to 34GB/s; 51 GB/s MAXN_SUPER)
Power
7W - 10W - 25W
Video Encode
1080p30 supported by 1-2 CPU cores
Video Decode
1x 4K60 (H.265)
2x 4K30 (H.265)
5x 1080p60 (H.265)
11x 1080p30 (H.265)
CSI camera
Up to 4 cameras
(8 via virtual channels***)
8 lanes MIPI CSI-2
D-PHY 2.1 (up to 20Gbps)
Mechanical
69.6mm x 45mm
260-pin SO-DIMM connector
Storage
1x M.2 KEY M PCIe (M.2 NVMe 2280 SSD 128G included)
Networking
M.2 KEY E
Mini PCIe
1x mini-PCIe for LTE 4G module
Ethernet
2x RJ45 Gigabit Ethernet
I/O
USB
Camera
4x mipi CSI(2-lane 15-Pin)
CAN
1 x CAN(4-Pin Header)
Display
1x HDMI 2.1
Fan
1x 4-Pin 1.25mm Fan Connector (5V PWM)
1x 4-Pin 2.54mm Fan Connector (12V PWM)
Extension Port
1x 40-Pin extension header
1x 12-Pin control and UART header
RTC
1x RTC 2-pin
1x RTC Socket
LED
2x LED(PWR and ACT)
Button
1x PWR
1x RESET
Switch
1x REC
Antenna hole
4x Antenna Hole
Power
12-19V 5525 Barrel DC Jack
Jetpack Version
Jetpack 6.2
Mechanical
Dimensions (W x D x H)
Weight
1110g
Installation
Desk, Wall-mounting
Operating Temperature
-20℃~65℃
Warranty
2 Years
Certification
RoHS,REACH,CE,FCC,UKCA, KC
