Supermicro: NVIDIA RTX PRO 6000 Server Edition GPU Server
Servers

Supermicro: NVIDIA RTX PRO 6000 Server Edition GPU Server

Arc Compute

Overview

2u rackmount server with dual AMD EPYC processors and 2x RTX Pro 6000 48GB GPUs. Supports up to 6TB DDR5 memory. Optimized for AI inference and enterprise compute workloads.

Key Features

  • Dual AMD EPYC processors
  • 2x RTX Pro 6000 with 48GB VRAM
  • Up to 6TB DDR5 memory
  • NVIDIA NVLink GPU interconnect
  • PCIe 5.0 expansion support

Ideal For

enterprise teams and research institutions running large-scale AI training, multi-GPU workloads, and enterprise inference deployments.

Model

  • • SYS-522GA-NRT
  • • AS -5126GS-TNRT

Form Factor

5U rack server

Processor

  • • 2x Intel Xeon 6900 series processors with P-cores Up to 128C/256T; Up to 504MB Cache per CPU
  • • 2x AMD EPYC 9005/9004 Series Processors Up to 192C/384T

GPU

  • • Max GPU Count: Up to 2 quad-width or 2 triple-width or 8 double-width or 10 single-width GPUs
  • • NVIDIA PCIe: NVIDIA RTX PRO™ 6000 Blackwell Server Edition
  • • CPU-GPU Interconnect: PCIe 5.0 x16 Switch Dual-Root
  • • GPU-GPU Interconnect: NVIDIAÂŽ NVLinkÂŽ Bridge (optional)

Memory

  • • Slot Count: 24 DIMM slots
  • • Max Memory (1DPC): Up to 6TB 6400MT/s ECC DDR5 RDIMM
  • • Max Memory (1DPC): Up to 6TB 8800MT/s ECC DDR5 MRDIMM

Storage

  • • Slot Count: 24 DIMM slots
  • • Standard 8x SSD 2.5" NVMe PCIe4 3.8TB 1DWPD TLC D, 15mm

Cooling

Air cooled

Fans

  • • Fans: 10 heavy duty fans with optimal fan speed control
  • • Air Shroud: 1 Air Shroud

Power Supply

6x 2700W Redundant Titanium Level (96%) power supplies

Dimensions

  • • Weight: Gross Weight: 100 lbs (45.3 kg)
  • • Net Weight: 65.5 lbs (29.7 kg)
  • • Available Color: Black Front & Silver Body

Warranty & Support

  • • 3-Year Standard RMA Warranty & Support
  • • Add On: 3-Year Next-Business-Day Onsite Warranty & Support
$109,999.00

Prices may vary. Verify on vendor site.

Quick Specs

Model
SYS-522GA-NRT
Form Factor
5U rack server
Processor
2x Intel Xeon 6900 series processors with P-cores Up to 128C/256T; Up to 504MB Cache per CPU
GPU
Max GPU Count: Up to 2 quad-width or 2 triple-width or 8 double-width or 10 single-width GPUs
Memory
Slot Count: 24 DIMM slots
Storage
Slot Count: 24 DIMM slots

Tags

llm-inferencedata-analytics
